Testing a BJT Transistor

This post is a blog on how to test a Bipolar Junction Transistor (BJT). The BJT transistor tested in the video is a PNP type. The majority of the BJTs that you come across will be NPN type transistors. Also, I uploaded some pics on what the voltage readings for both types will be with the multimeter set in the diode mode. Afterall, a Bipolar Junction Transistor has a makeup of two diodes put back to back, but sharing a common material (either the N or P material). PNP share the N (negative) material while NPN share the P (positive).

Going back, why are NPN transistors more common? PNP type transistors are difficult to bias as well as difficult to grasp lending quite a bit of confusion when you try to wrap your head around a circuit that contains one. This video only shows basic testing of a PNP type transistor not contained in a circuit. I know its a little difficult to see because I was using my new camera head-mount device (camera not included), but I hope you like it.

Here are the pics of the figures from an electronics book showing the voltage readings when the multimeter is set in the diode mode.
